Product Description And Features
The Large-Spot BGS Photoelectric Sensor is a high-performance solution designed for precise object detection, featuring a compact 12*21*31mm rectangular housing that allows for flexible integration in a variety of installation environments. It is ideal for demanding applications such as industrial automation, logistics sorting, and packaging lines. With a wide sensing range of 30-300mm, this sensor ensures accurate detection at varying distances, effectively suppressing background interference, making it especially suited for environments with limited space or complex backgrounds.
The sensor is equipped with a top-mounted potentiometer, allowing for quick adjustment of the sensing distance, while dual LED indicators provide clear visibility of both power and detection status. Whether in dimly lit warehouses, fast-moving production lines, or machinery with reflective backgrounds, this sensor consistently delivers stable and highly efficient performance.
Technical Specifications
| Output | Model |
| DC 4-Wire NPN NO/NC | GT-442N3-XGD |
| DC 4-Wire PNP NO/NC | GT-442P3-XGD |
| Technical specifications | |
| Detection type | BGS Diffuse reflection |
| Sensing distance | 30-300MM(Adjustable) |
| Adjustment method | Top potentiometer |
| Spot size | ≈6MMM |
| Supply voltage | 12-24V DC |
| light source | Red LED (650 nm) |
| Hysteresis distance | ＜5% |
| Current Rating | 20mA |
| Leakage Curren | ≤0.6mA |
| Response Time | 5ms |
| Response frequency(F) | 500Hz |
| load current | 200MA |
| Residual voltage | ＜1V |
| Circuit protection | Short-circuit ,EMl protectionrever sepolarityprotection |
| Indicator light | Green LED (power indicator) Red LED (sensing indicator) |
| Ambient illuminance | incandescent light≤3000Lux sunshine≤1000Lu |
| Ambient temperature | -25°C~+70°C |
| Vibration | 1mm amplitude at frequency 10~55Hz(for 1 min）ineach X.Y.Z direction for 2 hours |
| Protectiondegree | IP65 |
| Connection | 2M PVC Cable |
| Meterial | ABS |
